Hot Air Tape Welding Machine For Outdoor Tents
Parameter
| Model | TC-A8 |
Power | 220V 1phase |
Rating efficiency | 1800W |
Air pressure | 0.3-0.6MPa |
Effective tape width | 14-22mm |
Working speed | 0-23m/min |
Roller width | 25.4mm |
Temperature | up to 700°C |
Exterior dimensions(L×W×H) | 1,350×600×1,550mm |
Net weight | 185kg |
Features
1-Controlled by Panasonic programmable PLC with high definition display, English touch interface, process can be modified according to users' requirements.
2-Auto controllable temperature with high stability slightly varies between±2°C, Warning device for temperature upper limit is installed to protect heating wire.
3-It has the functions of synchro drive of the upper and lower wheel chain, auto compensation, and auto reverse.
4-Double pedal control is designed according to human mechanics, simple and comfortable, suitable for long-time operation.
5-It is possible to work 24 hours continuously with high efficiency.
6-Blowing-in wind can be filtrated without oil or water by unique heater tube.
7-Automatic tape loosen system can be added according to specific requirements.
8-The functions of auto tape clipping, sending and finishing reduce the wastage of raw material.
9-Super-thin lower column is suitable to sealing product with various sizes.
Application
Tents,car cover,boat cover,PVC laminated fabric,etc
